20162019 FORD EXPLORER TOW BAR MNTG BRKT KIT
$437.06
In stock
SKU
524445-5
2016-2019 FORD EXPLORER TOW BAR MNTG BRKT KIT, Vehicle Baseplate; EZ5 Series; Removable Tabs; With Safety Cable Hooks; With Brackets/ Base Plates/ Quick Disconnects And Mounting Hardware
Attributes
- Tab Type: Removable
- Number Of Lugs: 2
- Material: Steel
- Color: Black
- Includes Safety Cable Hooks: Yes
- Estimated Install Time (Hours): 3
Product Description
EZ4 and EZ5 brackets have a clean, uncluttered look, whether you're towing or driving. A spring-loaded locking system allows the brackets to be recessed even farther than earlier models. Both locks 'click' as each of the front arms are rotated into position; pull a ring and twist the front arms 90 Degrees to remove them. These brackets also have a convenient, built-in mounting point for the electrical socket.
Features & Benefits
- A Spring-Loaded Locking System Allows The Brackets To Be Recessed Even Farther Than Earlier Models
- Convenient, Built-In Mounting Point For The Electrical Socket
- Have A Clean, Uncluttered Look, Whether You're Towing Or Driving
- Limited 1 Year Warranty
Double Check all Measurements before ordering.
- 2016-2019 Ford Explorer
- 2016 Ford Explorer V6; 3.5L/3496; GAS; MFI; Duratec
- Bumper Fascia Must Be Removed And Replaced During Installation
- Requires Some Trimming Of Bumper (Fascia, Plastic, Grill)
- Requires Some Drilling (Not Major)
- This bracket will accommodate any ROADMASTER motorhome-mounted tow bar. This bracket is designed for heavier vehicles. Make sure the tow bar you use exceed the weight of the vehicle to be towed when full loaded. Anchor brackets for Sterling cables WILL NOT FIT MX or MS style brackets. To use MX or MS bracket with Sterling tow bar, the Sterling cable anchors must be attached to the frame of the vehicle or welded to the receiver portion of the bracket.
- Running Lights Must Be Relocated
- 2016 Ford Explorer V6; 3.5L/3496; GAS; DI; Turbocharged; EcoBoost
- Bumper Fascia Must Be Removed And Replaced During Installation
- Requires Some Trimming Of Bumper (Fascia, Plastic, Grill)
- Requires Some Drilling (Not Major)
- This bracket will accommodate any ROADMASTER motorhome-mounted tow bar. This bracket is designed for heavier vehicles. Make sure the tow bar you use exceed the weight of the vehicle to be towed when full loaded. Anchor brackets for Sterling cables WILL NOT FIT MX or MS style brackets. To use MX or MS bracket with Sterling tow bar, the Sterling cable anchors must be attached to the frame of the vehicle or welded to the receiver portion of the bracket.
- Running Lights Must Be Relocated
- 2017 Ford Explorer V6; 3.5L/3496; GAS; DI; Turbocharged; EcoBoost
- Bumper Fascia Must Be Removed And Replaced During Installation
- Requires Some Trimming Of Bumper (Fascia, Plastic, Grill)
- Requires Some Drilling (Not Major)
- This bracket will accommodate any ROADMASTER motorhome-mounted tow bar. This bracket is designed for heavier vehicles. Make sure the tow bar you use exceed the weight of the vehicle to be towed when full loaded. Anchor brackets for Sterling cables WILL NOT FIT MX or MS style brackets. To use MX or MS bracket with Sterling tow bar, the Sterling cable anchors must be attached to the frame of the vehicle or welded to the receiver portion of the bracket.
- Running Lights Must Be Relocated
- 2017 Ford Explorer V6; 3.5L/3496; GAS; MFI; Duratec
- Bumper Fascia Must Be Removed And Replaced During Installation
- Requires Some Trimming Of Bumper (Fascia, Plastic, Grill)
- Requires Some Drilling (Not Major)
- This bracket will accommodate any ROADMASTER motorhome-mounted tow bar. This bracket is designed for heavier vehicles. Make sure the tow bar you use exceed the weight of the vehicle to be towed when full loaded. Anchor brackets for Sterling cables WILL NOT FIT MX or MS style brackets. To use MX or MS bracket with Sterling tow bar, the Sterling cable anchors must be attached to the frame of the vehicle or welded to the receiver portion of the bracket.
- Running Lights Must Be Relocated
- 2018 Ford Explorer
- Bumper Fascia Must Be Removed And Replaced During Installation
- Requires Some Trimming Of Bumper (Fascia, Plastic, Grill)
- Requires Some Drilling (Not Major)
- This bracket will accommodate any ROADMASTER motorhome-mounted tow bar. This bracket is designed for heavier vehicles. Make sure the tow bar you use exceed the weight of the vehicle to be towed when full loaded. Anchor brackets for Sterling cables WILL NOT FIT MX or MS style brackets. To use MX or MS bracket with Sterling tow bar, the Sterling cable anchors must be attached to the frame of the vehicle or welded to the receiver portion of the bracket.
- Running Lights Must Be Relocated
- 2019 Ford Explorer
- Bumper Fascia Must Be Removed And Replaced During Installation
- Requires Some Trimming Of Bumper (Fascia, Plastic, Grill)
- Requires Some Drilling (Not Major)
- This bracket will accommodate any ROADMASTER motorhome-mounted tow bar. This bracket is designed for heavier vehicles. Make sure the tow bar you use exceed the weight of the vehicle to be towed when full loaded. Anchor brackets for Sterling cables WILL NOT FIT MX or MS style brackets. To use MX or MS bracket with Sterling tow bar, the Sterling cable anchors must be attached to the frame of the vehicle or welded to the receiver portion of the bracket.
- Running Lights Must Be Relocated
- 2016 Ford Explorer V6; 3.5L/3496; GAS; MFI; Duratec
| Weight | 62.000000 |
|---|---|
| mfg_part_number | 524445-5 |
| upc | 758306317338 |
| hazmat | yes |
| additional handling | Yes |
| oversized | yes |
